Welcome to DigitalSpeedometers.co.uk
Replacement Acewell digital speedos suitable for cars, bikes, quads and kitcars
Acewell - Ace 260 digital speedometersThe Acewell Ace 260 is an entry level speedometer and is ideal where a rev counter is not required.
The unit is complete with speedometer sensor & pickup and is able to utilize the existing fuel sender unit. Fully adjustable for all wheel sizes.
Has the following features, warning lights and functions as required by the IVA test.
- 2 x Trip meter
- Average & maximum speed functions
- 12/24 Hour clock
- Hours meter (current usage & total hours)
- Fuel Gauge
- Dimensions: 95mm x 52mm
Typical applications for digital speedometers
1. Recalibrate the speedo - The expensive option!
2. Replace with a digital speedo from the wide range available covering all needs - The cheaper option!
- Digital tachometer
- Trip meter
- Average speed
- Maximum speed
- Riding timer
- Total riding timer
- 50 Lap timer
Acewell Ace 3251 digital speedometersThe Acewell Ace 3251 is a more comprehensive digital dash than the Ace 260 entry level model above, but still manages to contain all the additional feutures within a small compact unit.
This model has a warning light surround with lights suitable for motorcycles or bike engined cars (e.g. kitcars).
It is completely adjustable for all wheel sizes and gearing. It can also be used with almost any 12v dc supply petrol engined vehicle and most diesels (some adaptation required on older diesel units). The Ace 3251 digital speedometers come complete with mounting bracket, speedo sensor, pickup, tacho sensing wire, temperature sender & uses an existing fuel sender.
- Backlit Speedometer 2.4 - 300KMH/187MPH
- 2 x Trip meter & odometer
- average & maximum speed functions
- Bar Graphic Tachometer 250 - 8,000 RPM or 500 - 16,000 RPM switchable option
- Digital Tachometer 100 - 19,900 RPM
- Bar Graphic Temp 1 - 7 bars displayed
- Digital Temp +50 to 180C or 122 - 356F
- Max temp warning light (adjustable setting)
- Voltage Meter 8.0 - 25 Volts
- Fuel - 1 to 7 bars of fuel & low fuel warning
- 12/24 Hour clock & hours meter (current usage & total hours)
- 2 x indicators
- main beam
- Rear fog
- Brake warning lights
All units come with full instructions & wiring diagram.
The Ace 3251 can be used with some manufacturers factory fitted speedo sender units which have a Hall effect sensor & generate a square wave with a voltage of at least 2.7V.
The central dash unit measures 95mm across the top, 85mm across the bottom, is 72mm high & 20mm deep (all measurements approximate), the warning light surround adds 14mm to each side & 3mm to the top & bottom of the unit.
The Acewell Digital speedometers shown here are just a small selection of the digital dashes that are available. To see the whole range and find out more details, visit the UK stockist Furore Products.
Any pre sales questions are probably already covered by their FAQ page, However if it isn’t, then contact their knowledgeable staff who will be able to answer any questions you may have prior to purchase.
